Description
| Model | 2 Door | 3 Door | 3 Door | |
|---|---|---|---|---|
| Silver Aluminium Door Frame | 2D/DCF-SM | 3D/D2C1F-SM | 3D/D2F1C-SM | |
| Temperature°C (celsius) | Chiller | +1 to +6 | +1 to +6 | +1 to +6 |
| Freezer | -20 to -14 | -20 to -14 | -20 to -14 | |
| External Dimension (mm) | 1260 x (710+20) x 2060 | 1880 x (710+20) x 2060 | 1880 x (710+20) x 2060 | |
| Gross Volume (Litres) | Chiller | 432 | 977 | 459 |
| Freezer | 403 | 459 | 977 | |
| Voltage/Frequency (V/Hz) | 230V/1/50Hz | 230V/1/50Hz | 230V/1/50Hz | |
| 220V/1/60Hz | 220V/1/60Hz | 220V/1/60Hz | ||
| Cooling Capacity (W) | Chiller | 522 | 792 | 522 |
| Freezer | 722 | 772 | 1112 | |
| Wattage (W) | 665 – 735 | 1045 – 1155 | 1425 – 1575 | |
| Ampere (A) | Chiller | 4.3 – 4.7 | 4.5 – 4.9 | 4.3 – 4.7 |
| Freezer | 4.5 – 4.9 | 5.3 – 5.9 | 7.6 – 8.4 | |
| Energy Consumption (kw/24h) | Chiller | 4.5 – 4.9 | 6.5 – 7.1 | 4.5 – 4.9 |
| Freezer | 14.5 – 16.1 | 14.5 – 16.1 | 20.4 – 22.6 | |
| Refrigerant | Chiller | R134a | R134a | R134a |
| Freezer | R404a | R404a | R404a | |
| PVC Coated Shelving | 10 | 15 | 15 | |
| Auto Door Lock | Yes | Yes | Yes | |
| Weight (kg) | 180 | 230 | 290 | |
| Unit For 20ft Container | 12 | 9 | 9 | |
| Unit For 40ft Container | 27 | 18 | 18 | |
